Littelfuse SMA6L Series - Manual (Page 2)

Transient Voltage Suppression Diodes
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 01/20/14
Surface Mount – 600W > SMA6L series
Electrical Characteristics
(T
A
=25°C unless otherwise noted)
Part
Number
(Uni)
Marking
Code
Reverse
Stand off
Voltage V
R
(Volts)
Breakdown
Voltage V
BR
(Volts) @ I
T
Test
Current
I
T
(mA)
Maximum
Clamping
Voltage V
C
@ I
pp
(V)
Maximum
Peak Pulse
Current I
pp
(A)
Maximum
Reverse
Leakage I
R
@ V
R
(µA)
Agency
Approval
MIN MAX
SMA6L5.0A AE 5.0 6.40 7.00 10 9.2 65.3 800 X
SMA6L6.0A AG 6.0 6.67 7.37 10 10.3 58.3 800 X
SMA6L6.5A AK 6.5 7.22 7.98 10 11.2 53.6 500 X
SMA6L7.0A AM 7.0 7.78 8.60 10 12.0 50.0 200 X
SMA6L7.5A AP 7.5 8.33 9.21 1 12.9 46.6 100 X
SMA6L8.0A AR 8.0 8.89 9.83 1 13.6 44.2 50 X
SMA6L8.5A AT 8.5 9.44 10.40 1 14.4 41.7 20 X
SMA6L9.0A AV 9.0 10.00 11.10 1 15.4 39.0 10 X
SMA6L10A AX 10.0 11.10 12.30 1 17.0 35.3 5 X
SMA6L11A AZ 11.0 12.20 13.50 1 18.2 33.0 1 X
SMA6L12A BE 12.0 13.30 14.70 1 19.9 30.2 1 X
SMA6L13A BG 13.0 14.40 15.90 1 21.5 28.0 1 X
SMA6L14A BK 14.0 15.60 17.20 1 23.2 25.9 1 X
SMA6L15A BM 15.0 16.70 18.50 1 24.4 24.6 1 X
SMA6L16A BP 16.0 17.80 19.70 1 26.0 23.1 1 X
SMA6L17A BR 17.0 18.90 20.90 1 27.6 21.8 1 X
SMA6L18A BT 18.0 20.00 22.10 1 29.2 20.6 1 X
SMA6L20A BV 20.0 22.20 24.50 1 32.4 18.6 1 X
SMA6L22A BX 22.0 24.40 26.90 1 35.5 16.9 1 X
SMA6L24A BZ 24.0 26.70 29.50 1 38.9 15.5 1 X
SMA6L26A CE 26.0 28.90 31.90 1 42.1 14.3 1 X
SMA6L28A CG 28.0 31.10 34.40 1 45.4 13.3 1 X
SMA6L30A CK 30.0 33.30 36.80 1 48.4 12.4 1 X
SMA6L33A CM 33.0 36.70 40.60 1 53.3 11.3 1 X
SMA6L36A CP 36.0 40.00 44.20 1 58.1 10.4 1 X
SMA6L40A CR 40.0 44.40 49.10 1 64.5 9.3 1 X
SMA6L43A CT 43.0 47.80 52.80 1 69.4 8.7 1 X
SMA6L45A CV 45.0 50.00 55.30 1 72.7 8.3 1 X
SMA6L48A CX 48.0 53.30 58.90 1 77.4 7.8 1 X
SMA6L51A CZ 51.0 56.70 62.70 1 82.4 7.3 1 X
SMA6L54A RE 54.0 60.00 66.30 1 87.1 6.9 1 X
SMA6L58A RG 58.0 64.40 71.20 1 93.6 6.5 1 X
SMA6L60A RK 60.0 66.70 73.70 1 96.8 6.2 1 X
SMA6L64A RM 64.0 71.10 78.60 1 103.0 5.9 1 X
SMA6L70A RP 70.0 77.80 86.00 1 113.0 5.3 1 X
SMA6L75A RR 75.0 83.30 92.10 1 121.0 5.0 1 X
SMA6L78A RT 78.0 86.70 95.80 1 126.0 4.8 1 X
SMA6L85A RV 85.0 94.40 104.00 1 137.0 4.4 1 X
