Surface Mount Fuses
Thin Film > 1206 Size > Very Fast-Acting > 466 Series
Average Time Current Curves
TIME IN SECONDS
CURRENT IN AMPERES
0.01
0.1
0.1
1
1
10
100
10 100
0.001
4A 3A 2 1/
2A
2A 1 3/
4A
1 1/
2A
1 1/
4A
1A 3/4A 1/2A 3/8A 1/4A 1/8A 5A
Reflow Condition Pb – free assembly
pre Heat
- Temperature min (T
s(min)
) 150°C
- Temperature max (T
s(max)
) 200°C
- Time (min to max) (t
s
) 60 – 180 seconds
Average Ramp-up Rate (liquidus Temp
(T
l
) to peak)
5°C/second max.
T
S(max)
to T
l
- Ramp-up Rate 5°C/second max.
Reflow
- Temperature (T
l
) (liquidus) 217°C
- Temperature (t
l
) 60 – 150 seconds
peak Temperature (T
p
) 260 +0/-5 °C
Time within 5°C of actual peak
Temperature (t
p
)
20 – 40 seconds
Ramp-down Rate 5°C/second max.
Time 25°C to peak Temperature (T
p
) 8 minutes max.
Do not exceed 260°C
Soldering Parameters
Temperature Rerating Curve
Wave Soldering 260°C, 10 seconds max.
Note:
1. Rerating depicted in this curve is in addition to the standard rerating of 25% for
continuous operation.
Example:
For continuous operation at 70 degrees celsius, the fuse should be rerated as follows:
I = (0.75)(0.80)I
RAT
= (0.60)I
RAT
2. The temperature derating curve represents the nominal conditions. For questions
about temperature derating curve, please consult Littelfuse technical support for
assistance.
Time
Te
mperatur
e
T
P
T
L
T
S(max)
T
S(min)
25
t
P
t
L
t
S
time to peak temperature
(t 25ºC to peak)
Ramp-down
Ramp-up
Preheat
Critical Zone
T L to T P
