Varistor Products

ZA Varistor Series

Radial Lead Varistors > ZA Series

Specifications are subject to change without notice.
Please refer to www.littelfuse.com/series/za.html for current information.

ZA S

eries

SYMBOL

DESCRIPTION

MODEL SIZE

5mm

7mm

10mm

14mm

20mm

P

Pitch of Component

12.7 +/- 1.0

12.7 +/- 1.0

25.4 +/- 1.0

25.4 +/- 1.0

25.4 +/- 1.0

P

0

Feed Hole Pitch

12.7 +/- 0.2

12.7 +/- 0.2

12.7 +/- 0.2

12.7 +/- 0.2

12.7 +/- 0.2

P

1

Feed Hole Center to Pitch

3.85 +/- 0.7

3.85 +/- 0.7

8.85 +/- 0.7

8.85 +/- 0.7

8.85 +/- 0.7

P

2

Hole Center to Component Center

6.35 +/- 1.0

6.35 +/- 1.0

12.7 +/- 0.7

12.7 +/- 0.7

12.7 +/- 0.7

F

Lead to Lead Distance

5.0 +/- 1.0

5.0 +/-1.0

7.5 +/- 1.0

7.5 +/- 1.0

7.5 +/- 1.0

h

Component Alignment

2.0 Max

2.0 Max

2.0 Max

2.0 Max

2.0 Max

W

Tape Width

18.0 +1.0 / -0.5

18.0 +1.0 / -0.5

18.0 +1.0 / -0.5

18.0 +1.0 / -0.5

18.0 +1.0 / -0.5

W

0

Hold Down Tape Width

12.0 +/- 0.3

12.0 +/- 0.3

12.0 +/- 0.3

12.0 +/- 0.3

12.0 +/- 0.3

W

1

Hole Position

9.0 +0.75 / -0.50 9.0 +0.75 / -0.50 9.0 +0.75 / -0.50 9.0 +0.75 / -0.50 9.0 +0.75 / -0.50

W

2

Hold Down Tape Position

0.5 Max

0.5 Max

0.5 Max

0.5 Max

0.5 Max

H

Height from Tape Center to

Component Base

18.0 +2.0 / -0.0

18.0 +2.0 / -0.0

18.0 +2.0 / -0.0

18.0 +2.0 / -0.0

18.0 +2.0 / -0.0

H

0

Seating Plane Height

16.0 +/- 0.5

16.0 +/- 0.5

16.0 +/- 0.5

16.0 +/- 0.5

16.0 +/- 0.5

H

1

Component Height

29.0 Max

32.0 Max

36.0 Max

40.0 Max

46.5 Max

D

0

Feed Hole Diameter

4.0 +/- 0.2

4.0 +/- 0.2

4.0 +/- 0.2

4.0 +/- 0.2

4.0 +/- 0.2

t

Total Tape Thickness

0.7 +/- 0.2

0.7 +/- 0.2

0.7 +/- 0.2

0.7 +/- 0.2

0.7 +/- 0.2

U

Undercrimp Width

8.0 Max

8.0 Max

8.0 Max

8.0 Max

8.0 Max

p

Component Alignment

3° Max

Max

3° Max

3° Max

3° Max

Tape and Reel Specifications (continued)

NOTES:
• Radial devices on tape are supplied with crimped leads, straight leads, or under-crimped leads
• Leads are offset by product dimension e1
• Conforms to ANSI and EIA specifications
• Can be supplied to IEC Publication 286-2
• 5mm parts are available on tape and reel up to 385 VAC only
