Littelfuse 1210L Series - Manual (Page 6)

POLY-FUSE ® Resettable PTCs
© 2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 11/05/13
Surface Mount > 1210L Series
TAPE SPECIFICATIONS: EIA-481-1 (mm)
REEL DIMENSIONS:
EIA-481-1 (mm)
Packaging Code “YR”:
1210L035
1210L050
1210L075
1210L110TH
Packaging Code “WR”:
1210L005
1210L010
1210L020
1210L110/12
1210L110/16
1210L150TH
1210L175
Packaging Code “PR”:
1210L075/24
1210L200
W 8.0+/- 0.30 8.0+/- 0.30 8.0+/- 0.30 H 12.0+/- 0.05
F 3.5+/- 0.05 3.5+/- 0.05 3.5+/- 0.05 W 9.0+/- 0.5
E
1
1.75+/- 0.10 1.75+/- 0.10 1.75+/- 0.10 D Ø 60+0.5
D
0
1.55+/- 0.05 1.55+/- 0.05 1.55+/- 0.05 F Ø 13.0+/- 0.2
D
1
1.0 (min) 1.0 (min) 1.0 (min) C Ø 178+/- 1.0
P
0
4.0+/- 0.10 4.0+/- 0.10 4.0+/- 0.10 H
1
11+/- 0.5
P
1
4.0+/- 0.10 4.0+/- 0.10 4.0+/- 0.10 W
1
2.2+/- 0.5
P
2
2.0+/- 0.05 2.0+/- 0.05 2.0+/- 0.05 W
2
3.0+0.5
A
0
2.82+/- 0.10 2.82+/- 0.10 2.67+/- 0.10 W
3
4.0+0.5
B
0
3.46+/- 0.10 3.46+/- 0.10 3.36+/- 0.10 W
4
5.5+0.5
T 0.25+/- 0.10 0.25+/- 0.10 0.25+/- 0.10
K
0
1.00+/- 0.10 1.30+/- 0.10 1.65+/- 0.10
Leader min. 390 390 390
Trailer min. 160 160 160
Tape and Reel Specifications
W
4
W
2
W
3
W
1
F
H
1
W
C
D
H
D
2
K
0 B
0 A
0
T
F
W
E
1
P
2
D
0
P
0
P
1
