TVS Diode Arrays
(SPA
®
Diodes)
© 2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: September 22, 2013
SP4020 Series
Lightning Surge Protection- SP4020 Series
Package Dimensions -SOD323
Symbol
SOD323
Millimeters
Inches
Min
Max
Min
Max
A
1.00
0.039
A1
0.00
0.10
0.000
0.004
A2
0.80
0.90
0.031
0.035
b
0.25
0.35
0.010
0.014
c
0.08
0.15
0.003
0.006
D
1.20
1.40
0.047
0.055
E
1.60
1.80
0.063
0.071
E1
2.50
2.70
0.098
0.106
L
0.475 REF
0.019 REF
L1
0.25
0.40
0.010
0.016
Ø
0º
8º
0º
8º
E
E1
b
L1
c
D
L
L
A1
A2
A
0.2
Ordering Information
Part Number
Package
Marking
Min. Order Qty.
SP4020-01FTG
SOD323
03
3000
SP4020-01FTG-C
SOD323
3C
3000
Part Numbering System
Part Marking System
SP
01
T G
Series
Number of
Channels
Package
T= Tape & Reel
G= Green
–
TVS Diode Arrays
(SPA
®
Diodes
)
F: SOD323
F
4020
C
Blank= Unidirectional
C= Bidirectional
03
3C
SP4020-01FTG
SP4020-01FTG-C
Embossed Carrier Tape & Reel Specification — SOD323
4.00
2.00
A
A
4.00
B
B
ø1.50
1.75
3.50
8.0
0
1.25
Cover Tape
2.90
B-B
0.254
1.46
A-A
ø178
12.3
9.5
12.3
54.4
R78.0
R25.6
R25.6
R6.5
3000
2500
2000
1500
1000
500
