HiQnet ™ Software
The Crown VRack has a unique advantage when used with Harman's HiQnet System Architect software.
The software is able to literally 'see' that your iTech4x3500HD amplifiers are in a rack, and specifically
they're in a VRack. You get specific advantages in speeding up deployment, programming, tuning, and
monitoring of a VRack powered system.
In addition, the user can combine the presets in all 3 VRack ampmlifiers into a single 'VRack Preset'. This
is done by loading the individual preset into each amplifier, and then using the VRack control panels'
'Preset' tab to save each individual preset into the same preset memory location on each amp. Now with
a single click, an 'entire rack' setting can be recalled. For most sound companies this means that with an
initial investment of some time in the shop, single-click 'entire rack' settings can be configured for most
of the PA in inventory, eliminating the need to program and recall individual presets in the field.
See page 42 for details.
HiQnet ™ Software
Preset Tab
Monitoring, Mutes, and Attenuation
Input Peak Meter
Output Overall Gain Reduction
(Limiting)
Output Peak Meter
Output RMS Meter
Output Clip Indication
Multi-Fader Attenuation
Channel Mutes and Mute All
Input RMS Meter
Input Clip Indication
Signal Generator Amp Info
Preset Name Indication
Voltage Monitoring
for all 3 Amplifiers
Digital Signal status
indicators (AES & CobraNet)
Recall Preset
Internal Switching
Frequency of DSP
Enable / Disable
Output Switching
Enable / Disable
Front Panel Lockout
Enable / Disable
USB Lockout
Store Preset
