Operation Manual

page 32

page 33

Operation Manual

Output Wiring Modes

2-Way + 1-Way Mode

1-Way Outputs

HP Nom Econ Max

VT4886

2

3

4

6

(Per Amplifier)

2-Way Outputs

HP Nom Econ Max

VT4887A

2

3

4

4

VT4887

2

3

4

4

(Per Amplifier)

Output Wiring Modes

1-Way + Sub Mode

HP Nom Econ Max

VT4880A

1

1

1

1

VT4880

1

1

2

2

VTX S28

1

1

1

1

VTX G28

1

1

1

1

VT4881A

2

2

3

3

VT4882

1

1

2

2

VT4883

1

1

2

2

(Per Amplifier)

Sub Outputs

1-Way Outputs

HP Nom Econ Max

VT4886

2

3

4

6

(Per Amplifier)
