Driverack ® 4800/4820 user Manual
6.10 - output Delay
The output channels of the DriveRack 4800 and 4820 provide up to 1360 mSec of configurable Delay,
this means that the Delay can be allocated to where it is needed.
Delay on/off switch
This turns the output channel Delay module on and off.
Delay fader
This sets the amount of delay time and is adjustable in either 10 or 20 µSec steps (one sample at either 96
or 48 kHz).
units switch
This selects what the Delay is expressed in, Seconds, Feet or Meters. The GUI shows all three simultane-
ously.
Detailed Parameters
Section 6
