Driverack – dbx DriveRack 4820 User Manual
Page 56
Detailed Parameters
Section 6
6.7 - output router
The Output Router lets you select from any of the input channels, adjust the Master Gain and Mute the
output.
Selected Source Switch
Allows selection between the input channels (Channels A-D).
Master Gain fader
Provides Gain control for the Router module (–inf to +20dB).
Master Mute switch
Provides Mute control for the Router module.
DriveRack
®
Driverack
®
4800/4820 user Manual
46
