3 of 56 ISSUED: 03-09-12 SHEET #: 095-9386-2 03-26-12
B
C D
E
G F
A
SA771PU-AB SA771PU-AW
Description Qty. Part # Part #
A wall arm assembly 1 095-S1994 095-S2994
B universal adapter bracket 1 095-S1635-1 095-S2635-1
C wood screws 4 520-1243 520-2243
D concrete anchors 4 590-0321 590-0321
E M10 x 15 mm socket head screw 2 520-9262 520-9534
F wall plate cover 2 590-1325 590-2325
G cable ties 16 590-1168 590-1168
H 6 mm allen wrench 1 560-9716 560-9716
I 5 mm allen wrench 1 560-9640 560-9640
J rear cable cover 4 590-P1326 590-2326
K front cable cover 4 590-P1327 590-2327
L Panasonic extension bracket 2 095-S1623 095-S2623
M Sharp extension bracket 2 095-S1622 095-S2622
N 1/4-20 self tapping screws 4 520-1633 520-2633
O M10 x 15 phillips screws 4 520-1305 520-2305
P 5/32" allen wrench 1 560-9646 560-9646
Parts List
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
J
N
O
L
M
K
H I P
