Slim Tilt Mount with PC Holder
For 25"-60" (63-152cm) Flat Panel TVs
Designed to wall mount smaller computers, the DS509 is a low-profile universal solution
for digital signage applications. Its bottom disengaging design allows the screen to have
a negative tilt that enables quick and easy computer maintenance without having to
remove the screen. Engineered for strength, durability and easy installation this mount
offers VESA compliance and is compatible with Peerless PLP adapter plate technology
to accommodate any flat panel display.
Fully Tilted At 10
Degrees
Universal
Compatibility
VESA ® and PLP
compliant
Component storage
Slim design houses
computers inside the
mount
perfeCt
viewing angle
0, 5 and 10 degree
tilt options
Max load: 200 lb (91kg)
DS509
 Rated to 200 lb (91 kg) for
dual studs, 60 lb (27 kg) for
single metal studs
 PLP adapter plate compliant
 VESA ® 100, 200, 100 x 200
and 200 x 100mm compliant
 Tilts at 0, 5 & 10 degrees
 Accommodates computers
up to 2.0" x 14.90" x 9.0"
(51 x 378 x 229mm)
 The computer can be
removed and serviced
without having to remove
the flat panel screen
 Screens can be mounted in
both landscape and portrait
CliCK: www.peerlessmounts.com Call: 800.865.2112 faX: 708.865.2941
featUres
Screen size: 25"-60" (63-152cm)
Computer Access * Wall interference could prohibit quick computer
access on screens over 40" (1016mm)
