Tilting Wall Mount
For 32" to 47" Displays
The SmartMountLT™ series tilting wall mounts are easy to install and offer display angle versatility.
Designed for medium to larger displays, the Hook-and-Hang™ system means even one person
can easily install even larger displays. The Easy-Glide™ adaptors easily hook into the wall plate
for quick, simple and secure installation. The low-profile design holds the display just 2.66" (67mm)
from the wall. After installation, use the side-to-side adjustment to perfectly position the display. The
+15°/-5° of tool-less tilt ensures you’ll always have the perfect viewing angle. With the IncreLok™ tilt
technology, you can lock the tilt angle at installation, and prevent tampering or moving. Plus, the
open wall plate allows total wall access, which increases electrical and cable management options.
Display size: 32"-47" Max load: 70lb (32kg)
STL646
 Fits 32" to 47" displays, up to
70lb (32kg)
 The low-profile design holds
the display just 2.66" (67mm)
from the wall creating an
ultra-low-profile finish perfect
for today’s ultra-slim displays
 Quick and easy,
Hook-and-Hang™
one-person installation
 Side-to-side adjustment
allows for perfect display
positioning
 +15°/-5° of tool-less tilt allows
you to adjust for the perfect
viewing angle
 Mounts to wood studs,
concrete, cinder block or
metal studs (metal stud
accessory required)
 Installation hardware
included
 UL Listed
 Five-year warranty
FeatureS
CLICK: peerless-av.com CaLL: 800.865.2112 FaX: 800.359.6500
hooK-and-hang™ SyStem
Offers easy, one-person
installation of the display Low-proFILe deSIgn
Holds display 2.66" (67mm)
from the wall, for a sleek
mounting solution
eaSy-gLIde™ adaptorS
Hooks onto the wall plate for quick,
simple and secure installation
open waLL pLate
Allows for total wall access and
increases electrical and cable
management options
SeCurIng SCrew
Locks the adaptor bracket onto
the wall plate, for a secure
installation
Low profile design — sits just
2.66 " (67mm) from the wall
+15°/-5° of tool-less tilt
InCreLoK™ tILt teChnoLogy
Locks tilt angle in place at -5°, 3°
or 9° to prevent tampering after
installation
