Simple inStallation
Display adapter simply
slides onto the wall plate
for a quick installation
VESA ® 200 x 100mm Tilt Wall Mount
for 10"-26" Flat Panel Displays
The sleek and compact YBT2X1 allows small displays to make a big impact in the room. Combined
with a simple hook and hang installation, the adjustable tilt allows flat panel displays to be
installed quickly and easily. The tilt is effortless to adjust without the use of any tools to achieve
the perfect viewing angle in any environment.
Display size: 10"-26" Max load: 25lb (11kg)
YBT2X1
 Fits 10"-26" flat panel
displays with VESA ® 75,
100 and 200 x 100mm
mounting hole patterns
 Slim design holds the display
only 2.24" (57mm) from
the wall for a low-profile
application
 ±15° of tool-less tilt
adjustment to achieve the
perfect viewing angle
 Display adapter simply
slides onto the wall plate
for a quick and easy
installation
 Mounts to wood stud,
concrete and cinder block
 Comes with all necessary
display attachment
hardware
 UL Listed
FeatureS
Standardized Compatibility
VESA ® 75, 100 and 200 x 100mm compliant
CliCK: www.peerless-av.com Call: 800.865.2112 FaX: 800.359.6500
Low-profile design holds
the display only 2.24"
(57mm) from the wall
±15° of tool-less tilt
adjustment to achieve the
perfect viewing angle
SeCure
Screw ensures flat panel display is
tightly secured to the wall plate
