Peerless-AV PLCK-UNL - Installation - Manual

Visit the Peerless Web Site at www.peerless-av.com For customer care call 708-865-2112.
1 of 9 ISSUED:02-22-07 SHEET #: 202-9197-5 (2013-10-01)
Maximum Load Capacity: 125 lb (57 kg)
Table of Contents
Parts List.................................................................................................................................................................................2
Attaching Extension Column To Ceiling Plate Or Existing Extension Column ........................................................................3
Attaching Ceiling Arm Box to Extension Column ....................................................................................................................4
PLCK-1 Installation .................................................................................................................................................................5
PLCK-UNL Installation ........................................................................................................................................................ 6-8
Installation and Assembly: Flat Panel Conversion Kit For
up to 50" LCD and Plasma Screens
Models: PLCK-UNL, PLCK-1
Read instruction sheet before you start installation and assembly.
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum Load Capacity.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal
injury.
WARNING
