ISSUED: 08-24-12 SHEET #: 180-9037-2 10-30-12
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated.
WL-SR560M-200
Description
Qty. Part Number
A screen mount bracket
1
201-1156
B hook plate
1
201-1157
C shelf support
1
201-1158
D base
1
009-1223
E universal plate
1
201-1110
F
adapter bracket
2
201-1510
G upright
1
580-1180
H top cover
1
590-1210
I
1/4-20 x 12mm decorative screw
22 520-2325
J
1/4-20mm nut
10 530-1050
L
3/8-16 x 2.5" socket screw
3
520-9550
M 7/32" allen wrench
1
560-9715
N
4 mm allen wrench
2
560-9646
O 8/32 nylock nut
6
530-1038
P
shelf pan
1
009-1225
Q 6 mm allen wrench
1
560-9716
R
left leg
1
009-1296
S
right leg
1
009-1295
T
wheel caster
2
600-0044
U
wheel caster/brake
2
600-0045
V
joint connector nut
4
530-1037
W 3/8-16 x 1.5" screw bolt
4
520-1329
X
M10 x .402 ID lock washer
3
540-9424
Z
3/16 allen wrench
1
560-0071
AA wireless receiver assembly
1
180-1092
BB power module assembly
1
180-1015
CC enclosure mounting bracket, small
4
120-1195
DD enclosure mounting bracket, large
4
120-1196
EE lock nut 1/4-20
8
530-1021
FF cable tie anchor
2
590-9469
GG cable tie .187 x 7.5 lg.
8
590-1168
HH cable tie .04 x 5.75 lg.
2
560-9711
II
cable management sheath
1
590-9468
JJ M10 x 15 mm socket screw
4
520-9262
Parts List
