9. Specifications
MODEL
ATS
INPUT
Input Voltage
220/230/240 VAC
Acceptable Input Voltage Range
180 - 258 VAC
Input Frequency
50 Hz/60 Hz
Maximum Input Current
16 A
OUTPUT
Output Voltage
220/230/240 VAC
Maximum Output Current
10 A for IEC-C13 outlets
16 A for IEC-C19 outlet
CONNECTION
Input
2 x IEC-C20 inlets
Output
8 x IEC-C13
1 x IEC-C19
Communication
USB/RS-232
TRANSFER TIME
9-12ms (Typical)
PHYSICAL
Dimension, D X W X H (mm)
330 X 483 X 44
Net Weight (kgs)
5.0
ENVIRONMENT
Operating Temperature
0-95 % RH @ -5°C- 45°C (non-condensing)
