232BRC-0812 Manual Appendix A: Cable Charts A-1
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104
B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91 792444 – Fax +353 91 792445
Appendix A: Cable Charts
All charts give full pinouts. Only pins 2 & 3 are required for basic
operation. Pins 7 and 8 are needed for hardware (RTS/CTS)
handshaking. If the connected device requires DTR or DSR, these
signals are available on pins 4 and 6 respectively. See Appendix B
for a block diagram of the 232BRC.
Port A Connections
Chart A.1. DTE (PC) DB9 Connector to Port A (DCE)
DTE (PC)
Serial Port
DB9 Connector
Signal
Direction
232BRC
Port A (DCE)
DB9F Connector
2 <----------- 2 (RD)
3 -----------> 3 (TD)
4 -----------> 4 (DTR)
5 <---------> 5 (GND)
6 <----------- 6 (DSR)
7 -----------> 7 (RTS)
8 <----------- 8 (CTS)
Chart A.2. DTE (PC) DB25 Connector to Port A (DCE)
DTE (PC)
Serial Port
DB25 Connector
Signal
Direction
232BRC
Port A (DCE)
DB9F Connector
2 -----------> 3 (TD)
3 <----------- 2 (RD)
4 -----------> 7 (RTS)
5 <---------- 8 (CTS)
6 <---------- 6 (DSR)
7 <---------> 5 (GND)
20 -----------> 4 (DTR)
