spECIFICatIons
SoFtware
Supported OS
A software CD is provided with programming kits
and contains Zlinx Manager software, Users Manual
and Quick Start Guide.
agenCy aPProValS
FCC Part 15 Class A
CE
Download DoC at www.bb-elec.com
Download DoC at www.bb-elec.com
UL/cUL
File Numbers E245458 (Class 1, Div 2) & E222870
(UL508)
Models that are Class 1/division 2 listed:
ZZ24D-Nx-SR (2.4GHz, Short range)
ZZ9D-Nx-LR (900 MHz, Long range)
ZZ-2AI2AO
ZZ-4AI
ZZ-4AO
ZZ-4AO-2
ZZ-4DI4DO-DCT
ZZ-4DI4DO-DCT1
ZZ-4RTD1
ZZ-8DI-DC
ZZ-8DO-R
ZZ-8DO-T
ZZ-8DO-T1
ZZ-PROG1-USB
Class 1, division 2 exceptions:
ZZ-8DO-R is not UL508 listed.
ZZxxD-Nx-MR, ZZxxD-Nx-xR-AU and ZZ8D-Nx-xR
models are not Class 1, Division 2 Listed but are
UL508 listed.
MtBF (hourS)
ZZ24D-NA-SR 85547 ZZ24D-NB-SR 137106
ZZ24D-NC-SR 86247 ZZ24D-ND-SR 138362
ZZ24D-NA-MR 88006 ZZ24D-NB-MR 142946
ZZ24D-NC-MR 88746 ZZ24D-ND-MR 144909
ZZ9D-NA-MR 88006 ZZ9D-NB-MR 144746
ZZ9D-NC-MR 88746 ZZ9D-ND-MR 144909
ZZ9D-NA-LR 88195 ZZ9D-NB-LR 143446
ZZ9D-NC-LR 88938 ZZ9D-ND-LR 145422
ZZ8D-NA-LR 88195 ZZ8D-NB-LR 143446
ZZ8D-NC-LR 88938 ZZ8D-ND-LR 145422
ZZ-4AI 136050 ZZ-4AO 113996
ZZ-2AI2AO 119183 ZZ-8DI-T 317530
ZZ-8DO-T 313100 ZZ-8DO-T1 317530
ZZ-4DI4DO-DCT 197045 ZZ-4DI4DO-DCT1 200795
ZZ-8DO-R 40670 ZZ-4RTD1 243007
ZZ-4AO-2 113996
Zlinx radio ModeM & i/o CoMPatiBility
radio Modem Zlinx Base i/o Module
ZP24D-250RM-SR ZZ24D-Nx-SR
ZP9D-115RM-LR ZZ9D-Nx-LR / ZZ9D-Nx-LR-AU
ZP8D-24RM-LR ZZ8D-Nx-LR
Power (BaSe ModuleS)
Source
An external power supply is required
(not included)
Voltage
10-40 VDC, 24 VAC
Class 2, (2.7A Maximum)
Power Connection Removable Terminal Block, 3.81 mm spacing
wiring terMinalS
Wire Type
Conductors
Wire Range
Tightening Torque
Field Wiring Temp Rating
Power Consumption
SR Models
900 MHz LR Models
868 MHz LR Models
Copper Wire Only
One Conductor Per Terminal
28 to 16 AWG
1.7 lb – in
105°C Minimum (Sized for 60°C ampacity).
10.0 W
9.5 W
12.0 W
Power (exPanSion ModuleS)
Source
Class 2 Power Derived from base modules
Voltage and current listed on product label.
Power Consumption
ZZ-4AI
ZZ-4AO
ZZ-2AI2AO
ZZ-8DI-DC
ZZ-8DO-T
ZZ-8DO-T1
ZZ-4DI4DO-DCT
ZZ-4DI4DO-DCT1
ZZ-8DO-R
ZZ-4RTD1
ZZ-4AO-2
1.0 W
1.1 W
1.2 W
0.4 W
15.8 W
1.1 W
8.1 W
1.0 W
3.2 W
0.4 W
6.0 W
outPutS
ZZ-8DO-R
Relay Output, 250VAC
2 A General Purpose/Point
8 A General Purpose Total
All Others
Low Voltage, Limited Energy
Communications Protocol
wire type
Conductors
Copper Wire Only
Wire Size One Conductor Per Terminal 28 to 16 AWG
Tightening Torque 0.2 Nm (Newton-Meters)
rePlaCeMent PartS
ZZ-DIN1
Replacement DIN clip and spring for all ZZ
products, also comes with spare screws for
enclosure
ZZ-TB1
Replacement terminal block kit for ZZ
products. Kit includes
(1) Two position TB (3.81mm)
(1) Four position TB (3.5mm)
(1) Eight position TB (3.5mm)
(1) Cover for local Bus
ZZ24D-ANT1 2.4 GHZ band antenna
ZZ9D-ANT1 900 MHz Spare Antenna
peer-to-peer and modbus I/o
Zlinx Standard Wireless I/O
continued...
