peer-to-peer and modbus I/o
Zlinx Standard Wireless I/O
analog inPutS and outPutS
Ranges:
0 to 10 VDC or 0 to 20 mA
ZZ-4AO-2 is an active current source. All
others are passive
Resolution: 12 Bit
Input Accuracy: 0.2% full scale reading typical
Output Accuracy: 0.27% full scale reading typical
AI Load Resistance:
100 Mega Ohms when configured for voltage
input 250 Ohms when configured for
current input
AO Max Output Current: 1 mA when configured for voltage output.
AO Max Load
450 Ohms when configured for current output
@ 12V
rtd inPutS
Number of RTD: 4
Wire Configuration: 2, 3, and 4 wire
Type:
PT100, PT1000 (Optimized for
temperature coefficient of 385 C),
Cu10 (Optimized for temperature
coefficient of 427 C)
Input Connection:
3.5mm removable terminal block
(4 per output)
Temperature Range:
PT100 = (-) 200 to (+) 650 C
PT1000 = (-) 200 to (+) 100 C
Cu10 = (-) 100 to (+) 260 C
Resolution: 0.1C cross at (-) 40 to (+) 80 C
Accuracy @ 25 C: (+/-) 0.5 C typical
Accuracy (-)40 to (+) 80C (+/-) 2.0 C maximum
enVironMental
operating temperature
ZZ-8DO-R
-40 to 55°C (-40 to 131°F)
All Others -40 to 80°C (-40 to 176°F)
MaxiMuM aMBient air teMPerature
ZZ-8DO-R 55°C (131°F)
All Others 80°C (176°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Operating Humidity 0 to 95% Non-condensing
Enclosure Plastic IP30
Mounting 35mm DIN Rail
Expansion
1 Base Module supports up to 6 Expansion
Modules
Dimensions
1.2 x 3.7 x 5.0 in
(2.9 x 9.3 x 12.7 cm)
spECIFICatIons
digital inPutS
Voltage Range: 0 to 48 VDC
Low Voltage (0): 0.8 V maximum
High Voltage (1): 4.0 V minimum
Pull Up Current: 38 micro-amps
Frequency Input:
2 DI inputs per module
Software selectable as
frequency counters,
0 to 5 KHz range.
digital outPutS
Voltage Range:
10 to 40 VDC (Sourcing)
0 to 48 VDC (Sinking)
40 mA per output
relay outPutS
Number of Relays: 8
Type: C -normally open & normally closed
Output Connection:
3.5mm removable terminal block
(2 per output)
Common Connection: 3.5mm removable terminal block
Ratings:
250VAC @ 8A, 30VDC @5A (maximum per bank of 4
as grouped on the label)
radio ProPertieS (2.4 ghZ - Sr ModelS)
Frequency: 2.4 GHz
Output Power: 100 mW
Receiver Sensitivity: -102 dbm
Antenna:
The included antenna is a 4.25 inch omni-directional
with RPSMA connector. (p/n ZZ24D-ANT1)
radio ProPertieS (900 Mhx - lr ModelS)
Frequency: 900 MHz
Output Power: 1W
Receiver Sensitivity: 100 dbm @ 115.2 K, 110 dbm @ 9.6K
Antenna:
The included antenna is a 6.5 inch omni-directional
with RPSMA connector. (p/n ZZ9D-ANT1)
radio ProPertieS (868 MhZ lr ModelS)
Frequency: 868 MHz
Output Power: 315 mW
Receiver Sensitivity: -112 dbm
Antenna:
The included antenna is a 6.5 inch omni-directional
with RPSMA connector. (p/n ZZ9D-ANT1)
led indiCatorS
Receive Signal Strength:
Tri-color – Off = No Signal
Red = Weak Signal
Yellow = Medium Signal
Green = Strong Signal
RF Data:
Green – Blinks with TD or RD
Off = No Data
Local Bus Data:
Green – Blinks with TD or RD
Off = No Data
Power:
Red – On = Power applied
Off = No Power
continued...
