peer-to-peer and modbus I/o
Zlinx Standard Wireless I/O
spECIFICatIons
BaSe Module radio ProPertieS
Model no. Frequency Software Selectable rF Power options
Factory rF Power
Setting
aeS encryption over-the-air data rate
ZZ24D-Nx-SR 2.4 GHz 10mW, 16mW, 25mW, 40mW, 63mW 63mW 128 Bit 250 Kbps
ZZ9D-Nx-LR 900 MHz * 1mW,10mW, 100mW, 500mW, 1000mW 1000mW 256 Bit 9.6 or 115.2 Kbps
ZZ9D-Nx-LR-AU 900 MHz * 1mW, 10mW, 100mW, 500mW, 1000mW 1000mW 128 Bit 9.6 or 115.2 Kbps
ZZ8D-Nx-LR 868 MHz ** 1mW, 23mW, 100mW, 159mW, 316mW 316mW 128 Bit 24 Kbps
Note: ZZ9D-Nx-LR and ZZ9D-Nx-LR-AU have software selectable OTA data rates.
range w/Supplied antenna (indoor / outdoor) maximum range w/high gain antenna (outdoor) maximum
ZZ24D-Nx-SR 300 Feet (91 Meters) / 1 Mile (1.6 Kilometers) N/A
ZZ9D-Nx-LR 3000 Feet (914 Meters) / 14 Miles (23 Kilometers) 40 Miles (64 Kilometers)
ZZ9D-Nx-LR-AU 3000 Feet (914 Meters) / 14 Miles (23 Kilometers) 40 Miles (64 Kilometers)
ZZ8D-Nx-LR 1800 Feet (549 Meters) / 25 Miles (40 Kilometers) 25 Miles (40 Kilometers)
*Note: 900 MHz units are not sold in Europe
** Note: 868 MHz units are not sold in North America
latenCy
Base Module Modbus Peer-to-Peer
Digital Analog Digital Analog
ZZ24D-xx-SR 8mS 15mS 20mS 25mS
ZZ9D-xx-LR 9mS 104mS 55mS 52mS
Latency times were measured in a clean RF environment with devices less than 3 feet (1m) apart.
Add 45mS per analog expansion module and 25mS per digital expansion module.
ZZ8D-Nx-LR radios have a 10% maximum duty cycle.
i/o PointS
Model no. digital inputs digital outputs analog inputs analog outputs
ZZxD-NA-xx (Base) 2 (Pull-up Resistors) 2 (Sourcing) 2 (mA, V) 2 (V, mA, Sinking)
ZZxD-NB-xx (Base) 4 (Pull-up Resistors) 4 (Sourcing) --- ---
ZZxD-NC-xx (Base) 2 (Pull-up Resistors) 2(Sinking) 2 (mA, V) 2 (V, mA, Sinking)
ZZxD-ND-xx (Base) 4 (Pull-up Resistors) 4 (Sinking) --- ---
ZZ-8DI-DC 8 (Pull-up Resistors) --- --- ---
ZZ-8DO-T --- 8 (Sourcing) --- ---
ZZ-8DO-T1 --- 8 (Sinking) --- ---
ZZ-4DI4DO-DCT 4 (Pull-up Resistors) 4 (Sourcing) --- ---
ZZ-4DI4DO-DCT1 4 (Pull-up Resistors) 4 (Sinking) --- ---
ZZ-4AI --- --- 4 (mA, V) ---
ZZ-4AO --- --- --- 4 (V, mA, Sinking)
ZZ-4A0-2 --- --- --- 4 (V, mA, Sourcing)
ZZ-2AI2AO --- --- 2 (mA, V) 2 (V, mA, Sinking)
ZZ-8DO-R --- 8 (Relay) --- ---
ZZ-4RTD1 --- --- 4 (RTD) ---
SoFtware PrograMMing kitS – required to PrograM your SySteM
Model number description
ZZ-PROG1-USB Programming Module (USB Interface), USB cable and Software CD
Note: The Software CD is only available with the programming kit. Software and Firmware can also be downloaded at www.bb-elec.com
