2
NOTE
Blinking does not display within iView².
The twisted pair port on the iMcV-Giga-MediaLinX includes AutoCross, a feature that
automatically selects between a crossover workstation or pass-through connection
depending on the connected device.
Installing iMcV-Giga-MediaLinX Modules
The iMcV-Giga-MediaLinX installs in any IMC Networks chassis, each requiring one
slot.
Step Action
1 To install a module, remove the blank brackets covering the slots where the
module is to be installed (if present) by removing the screws on the outside
edges of the bracket.
2 Slide the module into the chassis, via the card guides, until the module is
seated securely in the connector.
3 Secure the module to the chassis by tightening the captive screw.
4 Save any “blanks” removed during installation for future use should the
configuration requirements change.
