17
Powering Options
As a standalone unit, the PoE+ Giga-MiniMc uses a universal external desktop
switching power adapter. The PoE+ Giga-MiniMc also includes a DC terminal block
to support a voltage range of 51 to 57 VDC.
PoE+ Giga-MiniMc supports two powering options.
• Desktop AC power adapter with country specific power cord (included)
• The 4-terminal DC power block
DC Terminal Block Wiring Instructions
The PoE+ Giga-MiniMc can be powered via the DC terminal block. From a power
source, connect to any one positive and any one negative terminal on PoE+ Giga-
MiniMc.
PoE+ Giga-MiniMc
NOTE
When using stranded wire, the leads must be tinned, and equivalent to a 16 AWG solid
conductor. The
PoE+ Giga-MiniMc is protected against mis-wiring; if mis-wired the
PoE+ Giga-MiniMc will not function. The PoE+ Giga-MiniMc cannot support -48
VDC.
