B-2 Appendix B: Cable Charts Documentation Number 232BSS4 0812 Manual
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445
2 <----------- 3
(RD)
3 -----------> 2
(TD)
4 -----------> 20
(DTR) *
5 <---------> 7
(GND)
6 <----------- 6
(DSR) *
7 -----------> 4
(RTS)
8 <----------- 5
(CTS)
* - Pins 6, 8, & 20 looped back internally on the 232BSS4
