8

Documentation Number 232BSS4-0812m

B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com

B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com

Command Summary:

Three Character Command Format:

Char1

Char2

Command Char

Control Char

Control Char is only needed for Tx Only, Clear Buffer, and Ignore
Commands

Four Character Command Format:

Char1

Char2

Char3

Command Char

Control Char

Control Char is only needed for Tx Only, Clear Buffer, and Ignore
Commands

Table 2.1 - 232BSS4 Command Summary

Function

Command

Char.

Control

Char.

Comments

Select Port A Tx & Rx

“A”

None

Switching Command

Select Port B Tx & Rx

“B”

None

Switching Command

Select Port C Tx & Rx

“C”

None

Switching Command

Select Port D Tx & Rx

“D”

None

Switching Command

Deselect All Ports

EOT

None

Switching Command

Tx Only to Specific Ports

“S”

Dec 0 to 15

Use to Broadcast

Clear Buffer on Specific

Ports

“X”

Dec 0 to 15

Clear the Receive

Buffer

Ignore Commands

“T”

“0” to “9”

Sets Timer Value

Values in quotes “” are ASCII characters.
Dec. is an abbreviation for decimal value.


Command Explanation:

Where applicable, this section will provide an example of how to

create the command strings in Visual Basic. Other programming languages
may require a slightly different syntax, but the examples given should
provide enough information to port to other languages. For our examples,
we will use the default settings of the switch:

3 Character Command Sequence

Character 1 set to ASCII ESC character (Decimal 27)

Character 2 set to ASCII STX character (Decimal 2)

If you choose to use a four character command sequence, just add

another character between the second programmable character and the
command character in the command string.
