5
FUNCTION SWITCH SETTINGS RESULT [(D) = Default]
Loopback (iView 2 Configurable)
S1-1: OFF Loopback Disabled (D)
S1-1: ON Loopback Enabled
Loopback Type (iView 2 Configurable)
S1-2: OFF Coax (D)
S1-2: ON Fiber
Jitter Attenuation (iView 2 Configurable)
S1-3: OFF Jitter Attenuator on Receive Side
S1-3: ON Jitter Attenuator on Transmit Side (D)
FiberAlert (iView 2 Configurable)
S1-4: OFF FiberAlert Disabled (D)
S1-4: ON FiberAlert Enabled
Line Build-Out (iView 2 Configurable)
S1-5: OFF 0 to 255 ft.
S1-5: ON > 255 ft. (D)
Transmit Data Source (iView 2 Configurable)
S1-6: ON 7: ON Standard Data (D)
S1-6: OFF 7: ON Unframed All Ones
S1-6: ON 7: OFF Alternating Ones & Zeros
S1-6: OFF 7: OFF Pseudorandom Bit Sequence
DS3/E3/STS Selection
S1-8: ON 9: OFF 45 Mbps (DS3)
S1-8: OFF 9: ON 34 Mbps (E3)
S1-8: ON 9: ON 52 Mbps (STS)
Remote Unit
S1-10: OFF Remote Unit Disabled (D)
S1-10: ON Remote Unit Enabled
Feature Descriptions
The iMcV-DS3/E3/STS module includes several features that
allow it to be configured for varying DS3/E3/STS-based
environments.
Loopback
This switch enables or disables the loopback feature. When
this feature is enabled, the data line (Coax or Fiber) set
by the Loopback Type DIP Switch is looped back.
By default this feature is set to DISABLED.
