About the iMcV-DS3/E3/STS

iMcV-DS3/E3/STS is an SNMP-manageable module which converts
thin coax signals to single-mode or multi-mode fiber
signals at a data rate of 45 Mbps (DS3), 34 Mbps (E3) or 52
Mbps (STS). Each iMcV-DS3/E3/STS, BNC/FX module includes
one pair of BNC connectors and one pair of ST or SC fiber
optic connectors. This module must be installed in either,
an SNMP-manageable iMediaChassis chassis or an unmanaged
MediaChassis chassis.

Also available for single-strand fiber, iMcV-DS3/E3/STS,
BNC/SSFX includes one pair of BNC connectors and an SC
fiber optic connector. iMcV-DS3/E3/STS, BNC/SSFX modules
allow two wavelengths, for example, (1310 nm and 1550 nm)
to share one fiber strand, essentially doubling the
capacity of installed fiber.

iMcV-DS3/E3/STS modules must be deployed in pairs (one at
each end of a conversion). The data transmitted on the
fiber ports can only be received and interpreted by the
receive fiber of another iMcV-DS3/E3/STS. The single
strand versions must have opposite transmit and receive
wavelengths (for example one that transmits at 1310 nm must
be paired with another that receives at 1550 nm).

Installating an iMcV-DS3/E3/STS

iMcV-DS3/E3/STS modules can be installed in any
iMediaChassis, MediaChassis or IE-MediaChassis series
(remote modules can also be installed in any unmanaged
MediaChassis series or managed iMediaChassis series). Each
module requires one slot in the chassis. To install a
module, remove the blank brackets covering the slots where
the module is to be installed (if present) by removing the
screws on the outside edges of the bracket. Slide the
module into the chassis card guides, until the module is
securely seated in the connector. Secure the module to the
chassis by tightening the captive screw. Save any blanks
removed during installation for future use.

Configuration Instructions

Proper configuration of the iMcV-DS3/E3/STS is required for
maximum performance and reliability. The following
sections describe the prerequisites and the configurations
available for both managed and unmanaged modules.
