LDVDSV2-1587_2313DS Page 4
EMC Testing
Radiated RF Interference: SAE J1113/41
Load Dump and Transient Protection SAE J1113/11
ESD Immunity SAE J1113/13
Environmental Testing
Temperature Test:
Ten (10) temperature cycles as follows with unit operating normally
1. Room (25ºC) to Tmin in 15 minutes.
2. Soak at Tmin 1 Hour with power removed from unit
3. Start unit at Tmin, confirm successful start by executing a command/response. Power-down unit. Maintain
unit un-powered for one minute between power-ups.
4. Repeat Step 3 three times
5. Start unit at Tmin and ramp Tmin to Tmax in 30 minutes
6. Operate at Tmax for 1 hour
7. Ramp Tmax to Tmin in 15 minutes
8. Repeat steps 1 through 7 nine times for a total of 10 cycles:
a. 5 cycles at Vmin input
b. 5 cycles at Vmax input
Vibration Test:
IEC 60068-2-6
10 sweeps of 10 to 500 to 10Hz at rate 0.5 oct/min. each axis.
Level to be 1
0 to 36Hz, 0.06 in DA 36 to 500Hz, 4g’s
Unit must remain operational during and after the test.
Shock Test:
IEC 60068-2-27
18 to 50g’s, 11ms, ½ sine pulses, 3 each direction each axis
Unit must remain operational during and after the test.
Drop Test:
IEC 60068-2-32
10 Freefall drops from 1 meter onto concrete surface.
Drop 1 time one each face (6), 1 on a corner and the 3 edges of this corner.
The drop unit shall return to normal operation without physical damage.
