LDVDSV2-1587_2313DS Page 2
Additional Features

Outputs OBDII data in a J1708 data format

Ignition-On Signal Output
 Status LED’s for vehicle connection and power
Red
LED
(Power)
Green
LED
(Activity)
Red
LED
(Debug)
Actual State Customer Description
1 On On Off Normal operation Normal operation
2 On SB Off Detecting vehicle Detecting vehicle
3 Off FB Off Database version mismatch Database needs to be
updated
4 Off SB Off Update in progress Update in progress
5 Off VSB VSB Device asleep Device asleep
6 Off Off Off Device unpowered Device unpowered
7 Off On FB Error FPGA Image Invalid Firmware needs to be
updated
8 Off Off FB Error with EMM code Update System Manager
9 Off Off FB EMM checking CRC of
Images Wait 10 seconds if state
does not change see 8
10 Off SB FB Error writing/reading
to/from flash during update Restart update of current
component
LED state descriptions:

On (LED_ON): lit, solid

Off (LED_OFF): unlit

FB (LED_FAST): Alternating on-off; 125ms on, 125ms off

SB (LED_SLOW): Alternating on-off; .5 sec on, .5 sec off

VSB (LED_VERY_SLOW): Alternating on-off; .25 sec on, 2 sec off

Automatic low power mode senses when vehicle speed & engine speed is zero.

Automatic disconnect when technician scan tool is connected (Requires separate OBDII Y-Cable)

Proprietary vehicle detection algorithm and embedded database lets the same hardware work on all compliant vehicles

Wide Operating Temperature: -40 to 85 ºC (-40 to 185 ºF)

Low Power Consumption: 2W in Operating Mode; 0.15W in Automatic Sleep Mode (Key Off)
