Gigabit Fiber Transceiver (SFP) Characteristics
Fiber Length
550m* with
50/125 µm
10km** 40km** 70km**
TX Power Min/Max -9.5dBm/-4dBm -9.5dBm/-3.5dBm -2dBm/3dBm 0dBm/5dBm
RX Sensitivity Max -17dBm -20dBm -22dBm -24dBm
Wavelength 850nm 1310nm 1310nm 1550nm
Assumed Fiber Loss -0.5 dB/km -0.35 dB/km -0.25 dB/km
Laser Type VCSEL FP DFB DFB
*SX Fiber Optic Cable
** LX Fiber Optic Cable
Regulatory Approvals:
EMI: ANSI C63.4
CFR Title 47, Part 15, Subpart B - Class A
ICES-003 – Class A
EMC: EN 61000-6-2 (Immunity)
EN 61000-6-4 (Emissions)
IEC 61000-4-2 (ESD)
IEC 61000-4-3 (RFI)
IEC 61000-4-4 (EFT)
IEC 61000-4-5 (Surge)
IEC 61000-4-6 (RF)
IEC 61000-4-8 (PF)
IEC 61000-4-11 (Voltage Dips)
