CS10.481

CSeries

48V, 5A, S

INGLE

P

HASE

I

NPUT

Nov. 2006 / Rev.1.1 DS-CS10.481-EN
All parameters are specified at 48V, 5A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

www.pulspower.com Phone +49 89 9278 0 Germany

9/20

14. EMC

The CE mark is in conformance with EMC guideline 89/336/EEC and 93/68/EEC and the low-voltage directive (LVD)
73/23/EWG. A detailed EMC Report is available on request.

EMC Immunity

EN 61000-6-2, EN 61000-6-1

Generic standards

Electrostatic discharge

EN 61000-4-2

Contact discharge
Air discharge

8kV
15kV

Criterion A
Criterion A

Electromagnetic RF field

EN 61000-4-3 80MHz-1GHz

10V/m

Criterion

A

Fast transients (Burst)

EN 61000-4-4

Input lines
Output lines

4kV
2kV

Criterion A
Criterion A

Surge voltage on input

EN 61000-4-5

L Æ N
N / L Æ PE

2kV
4kV

Criterion A
Criterion A

Surge voltage on output

EN 61000-4-5

+ Ж -
+ / - Ж PE

500V
500V

Criterion A
Criterion A

Conducted disturbance

EN 61000-4-6

0,15-80MHz

10V

Criterion A

Mains voltage dips

EN 61000-4-11

0% of 100Vac

40% of 100Vac
70% of 100Vac
0% of 200Vac

40% of 200Vac
70% of 200Vac

0Vac, 20ms
40Vac, 200ms
70Vac, 500ms
0Vac, 20ms
80Vac, 200ms
140Vac, 500ms

Criterion A
Criterion C
Criterion C
Criterion A
Criterion C
Criterion C

Voltage interruptions

EN 61000-4-11

0Vac, 5000ms

Criterion C

Input voltage swells

PULS internal standard

300Vac, 500ms

Criterion A

Powerful transients

VDE 0160

over entire load
range

750V, 1.3ms

Criterion A

Criterions:

A: Power supply shows normal operation behavior within the defined limits.
C: Temporary loss of function is possible. Power supply might shut-down and restarts by itself. No damages or hazards for the
power supply occur.

Switching frequency

85kHz to 110kHz

input voltage dependent
