CS10.481
C–Series
48V, 5A, S INGLE P HASE I NPUT
Nov. 2006 / Rev.1.1 DS-CS10.481-EN
All parameters are specified at 48V, 5A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone +49 89 9278 0 Germany
20/20
25.12. M
OUNTING
O
RIENTATIONS
Mounting orientations other than input terminals on the bottom and output on the top require a reduction in
continuous output power or a limitation in the max. allowed ambient temperature. The amount of reduction
influences the lifetime expectancy of the power supply. Therefore, two different derating curves for continuous
operation can be found below:
Curve A1 Recommended output current.
Curve A2 Max allowed output current (results approx. in half the lifetime expectancy of A1).
Fig. 25-7
Mounting
Orientation A
Standard
Orientation
Power
Supply
OUTPUT
INPUT
Output Current
0
10 20 30 40 60°C
1.5
3
4.5
6A
50
A1
Ambient Temperature
Fig. 25-8
Mounting
Orientation B
(Upside down)
Pow er
Suppl y
OUTP UT
INPU T
Output Current
0
10 20 30 40 60°C
1.5
3
4.5
6A
50
A2
Ambient Temperature
A1
Fig. 25-9
Mounting
Orientation C
(Table-top
mounting) Output Current
0
10 20 30 40 60°C
1.5
3
4.5
6A
50
Ambient Temperature
A1
A2
Fig. 25-10
Mounting
Orientation D
(Horizontal cw)
Po
w
er
S
uppl
y
OUT
P
UT
INP
U
T
Output Current
0
10 20 30 40 60°C
1.5
3
4.5
6A
50
Ambient Temperature
A1
A2
Fig. 25-11
Mounting
Orientation E
(Horizontal ccw)
Po
w
er
S
uppl
y
OUT
P
UT
INP
U
T
Output Current
0
10 20 30 40 60°C
1.5
3
4.5
6A
50
Ambient Temperature
A1
A2
