Main Serial/Telnet Configuration Screen
After running through an initial self-test, the screen will display the following message:
“
configuration screen:
Saved Values — displays changes made during current session.
• IP Address (MUST be assigned during initial configuration)
• Subnet Mask (MUST be assigned during initial configuration)
• Default Gateway
• Server IP Address
• Prom File Name
Current Values — displays values currently in use.
• IP Address (IP address of SNMP agent)
• Subnet Mask (mask to define IP subnet to which agent is connected)
• Default Gateway (default router for IP traffic outside subnet)
• Server IP Address
• Prom File Name
Commands
• I = Enter New Saved Parameter Values
• P = Change Password
• T = New Trap Destination
• K = Remove ALL Trap Destinations
• C = New Community String
• U = Delete ALL Community Strings
• D = Enable/Disable DHCP
• E = End Session
• Space Bar = Opens device specific configuration options (tasks, memory,
cleandb, download, version, reboot, sysname, accounts, and modules).
Saved Values.
IP Address -
000.000.000.000
Subnet Mask -
000.000.000.000 DHCP is not active
Default Gateway -
000.000.000.000
Server IP Addr -
000.000.000.000
New Prom File -
promfilename
Current Values.
IP Address -
000.000.000.000
Subnet Mask -
000.000.000.000
Default Gateway –
000.000.000.000
Server IP Addr -
000.000.000.000
New Prom File -
promfilename
Community String:
public
Access:
r/w
Press
I
to enter new saved parameter values. Press
P
to change Password.
Press
T
to enter new Trap Destination. Press
K
to remove
ALL
Trap Destinations.
Press
C
to enter new Community String. Press
U
to remove
ALL
Community Strings.
Press
E
to End session. Type
REBOOT
to reboot unit. Press
D
for
DHCP
On/Off.
Press
SpaceBar
for additional commands.
