1
About the IE-iMcV-2xLIM, TX/SFP
The IE-iMcV-2xLIM, TX/SFP is a Fast Ethernet module which provides two
conversions of 100Base-TX twisted pair to 100Base-FX/SX single-mode or multi-
mode fiber. There are two sets of ports, each providing an RJ-45 (copper) to SFP
(fiber) an SFP, available in SC or LC connectors, 155 Mbps, can be installed in the
SFP port. Models with Configuration Control are identified by a label on the
faceplate of the module.
Also available in a single-strand fiber version, IE-iMcV-2xLIM, TX/SFP and IE-
iMcV-2xLIM, TX/SFP with Configuration Control allow two wavelengths to share
one fiber strand — Full-Duplex data travels on different wavelengths, for example
(1310 nm and 1550 nm) — doubling the capacity of fiber.
The IE-iMcV-2xLIM, TX/SFP is SNMP-manageable and can be installed into the
modular, SNMP-manageable iMediaChassis, the MediaChassis series, or the
MediaChassis series which are unmanaged.
A single DIP Switch bay offers configuration for each RJ-45 to fiber interface set:
DSW 1-5 for port 1 and DSW 6-10 for port 2.
Configuration Instructions
The IE-iMcV-2xLIM, TX/SFP has user-configurable maintenance features (e.g., TX
LinkLoss (TXLL), FX LinkLoss (FXLL), Link Fault Pass-Through (LFPT) and Far End
Fault (FEF)). Refer to the iMcV-Module DIP Switch configuration table for
information on available features. Instructions for configuring both managed (via
an SNMP-compatible management application like iView²) and unmanaged
modules follow.
