2.0 LM63 Registers
(Continued)
Fan Control Registers
(Continued)
Address
Hex
Read/
Write
Bits
POR
Value
Name Description
50
HEX
to 5F
HEX
LOOKUP TABLE (7 Bits for Temperature and 6 Bits for PWM for each Temperature/PWM Pair)
50
Read.
(Write
only if
reg
4A bit
5 = 1.)
7 0 Lookup Table
Temperature
Entry 1
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 51.
51
7:6 00 Lookup Table
PWM Entry 1
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 50.
52
7 0 Lookup Table
Temperature
Entry 2
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 53.
53
7:6 00 Lookup Table
PWM Entry 2
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 52.
54
7 0 Lookup Table
Temperature
Entry 3
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 55.
55
7:6 00 Lookup Table
PWM Entry 3
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 54.
56
7 0 Lookup Table
Temperature
Entry 4
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 57.
57
7:6 00 Lookup Table
PWM Entry 4
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 56.
58
7 0 Lookup Table
Temperature
Entry 5
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 59.
59
7:6 00 Lookup Table
PWM Entry 5
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 58.
5A
7 0 Lookup Table
Temperature
Entry 6
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 5B.
5B
7:6 00 Lookup Table
PWM Entry 6
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 5A.
5C
7 0 Lookup Table
Temperature
Entry 7
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 5D.
5D
7:6 00 Lookup Table
PWM Entry 7
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 5C.
5E
7 0 Lookup Table
Temperature
Entry 8
This bit is unused and always set to 0.
6:0 0x7F
If the remote diode temperature exceeds this value, the PWM output
will be the value in Register 5F.
5F
7:6 00 Lookup Table
PWM Entry 8
These bits are unused and always set to 0.
5:0 0x3F The PWM value corresponding to the temperature limit in register 5E.
4F
HEX
LOOKUP TABLE HYSTERESIS
4F R/W
7:5 000
Lookup
Table
Hysteresis
These bits are unused and always set to 0
4:0 00100 The amount of hysteresis applied to the Lookup Table. (1 LSB = 1˚C).
LM63
www.national.com 18
