MAX1519/MAX1545
Dual-Phase, Quick-PWM Controllers for
Programmable CPU Core Power Supplies
______________________________________________________________________________________ 23
for an additional 24 clock cycles after the controller
reaches the final DAC code value.
UVP can be disabled through the “no-fault” test mode
(see the No-Fault Test Mode section).
Thermal-Fault Protection
The MAX1519/MAX1545 feature a thermal fault-protec-
tion circuit. When the junction temperature rises above
+160°C, a thermal sensor activates the fault latch and
activates the soft-shutdown sequence. Once the con-
CODE = V CC
D4 D3 D2 D1 D0
OUTPUT
VOLTAGE
(V)
0 0 0 0 0 1.750
0 0 0 0 1 1.700
0 0 0 1 0 1.650
0 0 0 1 1 1.600
0 0 1 0 0 1.550
0 0 1 0 1 1.500
0 0 1 1 0 1.450
0 0 1 1 1 1.400
0 1 0 0 0 1.350
0 1 0 0 1 1.300
0 1 0 1 0 1.250
0 1 0 1 1 1.200
0 1 1 0 0 1.150
0 1 1 0 1 1.100
0 1 1 1 0 1.050
0 1 1 1 1 1.000
1 0 0 0 0 0.975
1 0 0 0 1 0.950
1 0 0 1 0 0.925
1 0 0 1 1 0.900
1 0 1 0 0 0.875
1 0 1 0 1 0.850
1 0 1 1 0 0.825
1 0 1 1 1 0.800
1 1 0 0 0 0.775
1 1 0 0 1 0.750
1 1 0 1 0 0.725
1 1 0 1 1 0.700
1 1 1 0 0 0.675
1 1 1 0 1 0.650
1 1 1 1 0 0.625
1 1 1 1 1 0.600
Table 4. Output Voltage VID DAC Codes (SUS = GND)
CODE = GND
D4 D3 D2 D1 D0
OUTPUT
VOLTAGE
(V)
0 0 0 0 0 1.850
0 0 0 0 1 1.825
0 0 0 1 0 1.800
0 0 0 1 1 1.775
0 0 1 0 0 1.750
0 0 1 0 1 1.725
0 0 1 1 0 1.700
0 0 1 1 1 1.675
0 1 0 0 0 1.650
0 1 0 0 1 1.625
0 1 0 1 0 1.600
0 1 0 1 1 1.575
0 1 1 0 0 1.550
0 1 1 0 1 1.525
0 1 1 1 0 1.500
0 1 1 1 1 1.475
1 0 0 0 0 1.450
1 0 0 0 1 1.425
1 0 0 1 0 1.400
1 0 0 1 1 1.375
1 0 1 0 0 1.350
1 0 1 0 1 1.325
1 0 1 1 0 1.300
1 0 1 1 1 1.275
1 1 0 0 0 1.250
1 1 0 0 1 1.225
1 1 0 1 0 1.200
1 1 0 1 1 1.175
1 1 1 0 0 1.150
1 1 1 0 1 1.125
1 1 1 1 0 1.100
1 1 1 1 1 Shutdown
