MAX108
±5V, 1.5Gsps, 8-Bit ADC with
On-Chip 2.2GHz Track/Hold Amplifier
_______________________________________________________________________________________ 3
DC ELECTRICAL CHARACTERISTICS (continued)
(V CC A = V CC I = V CC D = +5.0V ±5%, V EE = -5.0V ±5%, V CC O = +3.0V to V CC D, REFIN connected to REFOUT, T A = T MIN to T MAX ,
unless otherwise noted. Typical values are at T A = +25°C.)
PECL DIGITAL OUTPUTS (Note 5)
Negative Power-Supply
Rejection Ratio (Note 8)
PSRR- 40 68 dB (Note 10)
Common-Mode Rejection Ratio
(Note 7)
CMRR 40 68 dB
Positive Power-Supply Rejection
Ratio (Note 8)
PSRR+ 40 73 dB
VIN+ = VIN- = ±0.1V
(Note 9)
Positive Analog Supply Current I CC A 480 780 mA
Positive Input Supply Current I CC I 108 150 mA
Negative Input Supply Current I EE -290 -210 mA
Digital Supply Current I CC D 205 340 mA
Output Supply Current (Note 6) I CC O 75 115 mA
Power Dissipation (Note 6) P DISS 5.25 W
Digital Output High Voltage V OH -1.025 -0.880 V
Digital Output Low Voltage V OL -1.810 -1.620 V
PARAMETER SYMBOL MIN TYP MAX UNITS
High-Level Input Voltage V IH 2.0 V
Low-Level Input Voltage V IL 0.8 V
High-Level Input Current I IH 50 µA
Clock Input Resistance R CLK 48 50 52
Ω
Input Resistance Temperature
Coefficient
TC R 150 ppm/°C
Low-Level Input Current I IL -1 1 µA
Digital Input High Voltage V IH -1.165 V
Digital Input Low Voltage V IL -1.475 V
CONDITIONS
V IL = 0
V IH = 2.4V
CLK+ and CLK- to CLKCOM, T A = +25°C
CLOCK INPUTS (Note 3)
TTL/CMOS CONTROL INPUTS (DEMUXEN, DIVSELECT)
DEMUX RESET INPUT (Note 4)
POWER REQUIREMENTS
PECL DIGITAL OUTPUTS (Note 5)
