Page 7
ns
MAX1401
+3V, 18-Bit, Low-Power, Multichannel,
Oversampling (Sigma-Delta) ADC
_______________________________________________________________________________________
7
Note 16:
These specifications apply to CLKOUT only when driving a single CMOS load.
Note 17:
The burn-out currents require a 500mV overhead between the analog input voltage and both V+ and AGND to operate
correctly.
Note 18:
Measured at DC in the selected passband. PSR at 50Hz will exceed 120dB with filter notches of 25Hz or 50Hz and FAST
bit = 0. PSR at 60Hz will exceed 120dB with filter notches of 20Hz or 60Hz and FAST bit = 0.
Note 19:
PSR depends on gain. For a gain of +1V/V, PSR is 70dB typical. For a gain of +2V/V, PSR is 75dB typical. For a gain of
+4V/V, PSR is 80dB typical. For gains of +8V/V to +128V/V, PSR is 85dB typical.
Note 20:
Standby power-dissipation and current specifications are valid only with CLKIN driven by an external clock and with the
external clock stopped. If the clock continues to run in standby mode, the power dissipation will be considerably higher.
When used with a resonator or crystal between CLKIN and CLKOUT, the actual power dissipation and I
DD
in standby
mode will depend on the resonator or crystal type.
TIMING CHARACTERISTICS
(V+ = +2.7V to +3.6V, V
DD
= +2.7V to +3.6V, AGND = DGND, f
CLKIN
= 2.4576MHz, input logic 0 = 0V, logic 1 = V
DD
, T
A
= T
MIN
to
T
MAX
, unless otherwise noted.) (Notes 21, 22, 23)
0
100
Bus-Relinquish Time After SCLK
Rising Edge (Note 28)
t
10
10
100
ns
SCLK Falling Edge to Data Valid
Delay (Notes 26, 27)
t
6
ns
INT High Time
t
INT
560 / N
·
t
CLKIN
ns
X2CLK = 1, N = 2
(2
·
MF1 + MF0)
X2CLK = 1
X2CLK = 0
SCLK Setup to Falling Edge CS
t
4
30
ns
SCLK Low Pulse Width
t
8
100
ns
CS Rising Edge to SCLK Rising
Edge Hold Time (Note 23)
t
9
0
ns
SCLK High Pulse Width
t
7
100
ns
CS Falling Edge to SCLK Falling
Edge Setup Time
t
5
30
ns
280 / N
·
t
CLKIN
INT to CS Setup Time (Note 10)
t
3
X2CLK = 0, N = 2
(2
·
MF1 + MF0)
0
ns
RESET Pulse Width Low
t
2
100
ns
Master Clock Input Low Time
f
CLKIN LO
0.4
·
t
CLKIN
ns
t
CLKIN
= 1 / f
CLKIN
, X2CLK = 0
Master Clock Input High Time
f
CLKIN HI
0.4
·
t
CLKIN
ns
t
CLKIN
= 1 / f
CLKIN
, X2CLK = 0
Master Clock Frequency
f
CLKIN
0.8
5.0
MHz
Crystal oscillator or clock
externally supplied for
specified performance
(Notes 24, 25)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
0.4
2.5
CONDITIONS
SCLK Rising Edge to INT High
(Note 29)
t
11
200
ns
SERIAL-INTERFACE READ OPERATION
