Pin Descriptions and Equivalent Circuits
(LLP pins in parentheses) (Continued)
Pin
No.
Symbol Equivalent Circuit Description
11,
13, 14
(9, 11,
12)
DV
DD
Positive digital supply pin. Connect to a clean, quiet
voltage source of +5V. AV
DD
and DV
DD
should have
a common source and be separately bypassed with
a 10 µF capacitor and a 0.1 µF ceramic chip
capacitor. See Section 4.0 for more information.
2, 24
(22,
24)
DV
SS
The ground return for the digital supply. AV
SS
and
DV
SS
should be connected together close to the
ADC1175-50.
15, 18
(13,
16)
AV
DD
Positive analog supply pin. Connect to a clean,
quiet voltage source of +5V. AV
DD
and DV
DD
should
have a common source and be separately bypassed
with a 10 µF capacitor and a 0.1 µF ceramic chip
capacitor. See Section 4.0 for more information.
20, 21
(18,
19)
AV
SS
The ground return for the analog supply. AV
SS
and
DV
SS
should be connected together close to the
ADC1175-50 package.
