15
4951A–AUTO–08/06
ATA6832
12. Package Information
11. Ordering Information
Extended Type Number Package Remarks
ATA6832-PFQW QFN18 Taped and reeled, Pb-free
specifications
according to DIN
technical drawings
0.45
±0.1
18
1
6
Pin 1 identification
13 18
12
7
1
6
Package: VQFN_4 x 4_18L
Exposed pad 2.5 x 3.125
Dimensions in mm
Not indicated tolerances ±0.05
Issue: preliminary copy; 06.10.06
Drawing-No.: 6.543-5133.01-4
0.2
2.5
0.5 nom.
Z
2.5
2.6 ±0.15
3.125
±0.15
Z 10:1
0.9 ±0.1
0.23 ±0.07
4
Top
Bottom
