ATF16V8B(QL)
3
Notes: 1. Not more than one output at a time should be shorted. Duration of short circuit test should not exceed 30 sec.
2. Shaded parts are obsolete with a last time buy date of 19 August 1999.
DC Characteristics
Symbol Parameter Condition Min Typ Max Units
I
IL
Input or I/O Low
Leakage Current
0
≤=V
IN
≤=V
IL
(Max) -35 -100 µA
I
IH
Input or I/O High
Leakage Current
3.5 ≤=V
IN
≤=V
CC
10 µA
I
CC
Power Supply
Current, Standby
V
CC
= Max,
V
IN
= Max,
Outputs Open
B-7, -10
Com. 55 85 mA
Ind. 55 95 mA
B-15 Com. 50 75 mA
B-15 Ind. 50 80 mA
B-25 Com. 50 75 mA
B-25 Ind. 50 80 mA
BQ-10 Com. 35 55 mA
BQL-15 Com. 5 10 mA
BQL-15 Ind. 5 15 mA
BQL-25 Com. 5 10 mA
BQL-25 Ind. 5 15 mA
I
CC2
Clocked Power
Supply Current
V
CC
= Max,
Outputs Open,
f=15 MHz
B-7, -10
Com. 60 90 mA
Ind. 60 100 mA
B-15 Com. 55 85 mA
B-15 Ind. 55 95 mA
B-25 Com. 55 85 mA
B-25 Ind. 55 95 mA
BQ-10 Com. 40 55 mA
BQL-15 Com. 20 35 mA
BQL-15 Ind. 20 40 mA
BQL-25 Com. 20 35 mA
BQL-25 Ind. 20 40 mA
I
OS
(1)
Output Short
Circuit Current
V
OUT
= 0.5 V -130 mA
V
IL
Input Low Voltage -0.5 0.8 V
V
IH
Input High Voltage 2.0 V
CC
+0.75 V
V
OL
Output High Voltage
V
IN
=V
IH
or V
IL
,
V
CC
=Min
I
OL
= -24 mA
Com., Ind.
0.5 V
V
OH
Output High Voltage
V
IN
=V
IH
or V
IL
,
V
CC
=Min
I
OH
= -4.0 mA 2.4 V
