ATF16V8B(QL)
17
Note: 1. Shaded parts are obsolete with a last time buy date of 11 August 1999.
Using “C” Product for Industrial
To use commercial product for Industrial temperature ranges, down-grade one speed grade from the “I” to the “C” device
(7 ns “C” = 10 ns “I”) and de-rate power by 30%.
ATF16V8BQ and ATF16V8BQL Ordering Information
t
PD
(ns)
t
S
(ns)
t
CO
(ns) Ordering Code Package Operation Range
10 7.5 7 ATF16V8BQ-10JC
ATF16V8BQ-10PC
ATF16V8BQ-10SC
ATF16V8BQ-10XC
20J
20P3
20S
20X
Commercial
(0 °C to 70°C)
15 12 10 ATF16V8BQL-15JC
ATF16V8BQL-15PC
ATF16V8BQL-15SC
ATF16V8BQL-15XC
20J
20P3
20S
20X
Commercial
(0 °C to 70°C)
ATF16V8BQL-15JI
ATF16V8BQL-15PI
ATF16V8BQL-15SI
ATF16V8BQL-15XI
20J
20P3
20S
20X
Industrial
(-40
°C to 85°C)
25 15 12 ATF16V8BQL-25JC
ATF16V8BQL-25PC
ATF16V8BQL-25SC
ATF16V8BQL-25XC
20J
20P3
20S
20X
Commercial
(0 °C to 70°C)
ATF16V8BQL-25JI
ATF16V8BQL-25PI
ATF16V8BQL-25SI
ATF16V8BQL-25XI
20J
20P3
20S
20X
Industrial
(-40 °C to 85°C)
Package Type
20J 20-lead, Plastic J-leaded Chip Carrier (PLCC)
20P3 20-lead, 0.300" Wide, Plastic Dual Inline Package (PDIP)
20S 20-lead, 0.300" Wide, Plastic Gull-Wing Small Outline (SOIC)
20X 20-lead, 4.4 mm Wide, Plastic Thin Shrink Small Outline (TSSOP)
