OSCILLATOR CONTROL BITS
When the DS12887 is shipped from the factory, the internal oscillator is turned off. This feature prevents
the lithium energy cell from being used until it is installed in a system. A pattern of 010 in bits 4 through
6 of Register A turns the oscillator on and enables the countdown chain. A pattern of 11X turns the
oscillator on, but holds the countdown chain of the oscillator in reset. All other combinations of bits 4
through 6 keep the oscillator off.
SQUARE-WAVE OUTPUT SELECTION
Thirteen of the 15 divider taps are made available to a 1-of-15 selector, as shown in the block diagram of
Figure 1. The first purpose of selecting a divider tap is to generate a square-wave output signal on the
SQW pin. The RS0–RS3 bits in Register A establish the square-wave output frequency. These
frequencies are listed in Table 1. The SQW frequency selection shares its 1–of–15 selector with the
periodic interrupt generator. Once the frequency is selected, the output of the SQW pin can be turned on
and off under program control with the square-wave enable bit (SQWE).
PERIODIC INTERRUPT SELECTION
The periodic interrupt causes the IRQ pin to go to an active state from once every 500ms to once every
122 ms. This function is separate from the alarm interrupt, which can be output from once per second to
once per day. The periodic interrupt rate is selected using the same Register A bits, which select the
square-wave frequency (Table 1). Changing the Register A bits affect both the square-wave frequency
and the periodic-interrupt output. However, each function has a separate enable bit in Register B. The
SQWE bit controls the square-wave output. Similarly, the periodic interrupt is enabled by the PIE bit in
Register B. The periodic interrupt can be used with software counters to measure inputs, create output
intervals, or await the next needed software function.
UPDATE CYCLE
The DS12887 executes an update cycle once per second regardless of the SET bit in Register B. When
the SET bit in Register B is set to 1, the user copy of the double-buffered time, calendar, and alarm bytes
is frozen and will not update as the time increments. However, the time countdown chain continues to
update the internal copy of the buffer. This feature allows time to maintain accuracy independent of
reading or writing the time, calendar, and alarm buffers and also guarantees that time and calendar
information is consistent. The update cycle also compares each alarm byte with the corresponding time
byte and issues an alarm if a match or if a “don’t care” code is present in all three positions.
There are three methods that can handle access of the RTC that avoid any possibility of accessing
inconsistent time and calendar data. The first method uses the update-ended interrupt. If enabled, an
interrupt occurs after every update cycle that indicates that over 999ms are available to read valid time
and date information. If this interrupt is used, the IRQF bit in Register C should be cleared before leaving
the interrupt routine.
A second method uses the update-in-progress bit (UIP) in Register A to determine if the update cycle is in
progress. The UIP bit pulses once per second. After the UIP bit goes high, the update transfer occurs
244
ms later. If a low is read on the UIP bit, the user has at least 244ms before the time/calendar data is
