DS12887

12 of 19

REGISTER B

MSB

LSB

BIT 7

BIT 6

BIT 5

BIT 4

BIT 3

BIT 2

BIT 1

BIT 0

SET

PIE

AIE

UIE

SQWE

24/12

DSE

SET – When the SET bit is a 0, the update transfer functions normally by advancing the counts once per
second. When the SET bit is written to a 1, any update transfer is inhibited and the program can initialize
the time and calendar bytes without an update occurring in the midst of initializing. Read cycles can be
executed in a similar manner. SET is a read/write bit that is not modified by

RESET

or internal functions

of the DS12887.

PIE – The periodic-interrupt enable (PIE) bit is a read/write bit that allows the periodic-interrupt flag
(PF) bit in Register C to drive the

IRQ

pin low. When the PIE bit is set to 1, periodic interrupts are

generated by driving the

IRQ

pin low at a rate specified by the RS3–RS0 bits of Register A. A 0 in the

PIE bit blocks the

IRQ

output from being driven by a periodic interrupt, but the periodic flag (PF) bit is

still set at the periodic rate. PIE is not modified by any internal DS12887 functions, but is cleared to 0 on

RESET

AIE – The alarm interrupt enable (AIE) bit is a read/write bit that, when set to a 1, permits the alarm flag
(AF) bit in Register C to assert

IRQ

. An alarm interrupt occurs for each second that the three time bytes

equal the three alarm bytes, including a “don’t care” alarm code of binary 11XXXXXX. When the AIE
bit is set to 0, the AF bit does not initiate the

IRQ

signal. The

RESET

pin clears AIE to 0. The internal

functions of the DS12887 do not affect the AIE bit.

UIE – The update-ended interrupt enable (UIE) bit is a read/ write that enables the update-end flag (UF)
bit in Register C to assert

IRQ

. The

RESET

pin going low or the SET bit going high clears to UIE bit.

SQWE – When the square-wave enable (SQWE) bit is set to a 1, a square-wave signal at the frequency
set by the rate-selection bits RS3 through RS0 is driven out on a SQW pin. When the SQWE bit is set to
z0, the SQW pin is held low; the state of SQWE is cleared by the

RESET

pin. SQWE is a read/write bit.

DM – The data mode (DM) bit indicates whether time and calendar information is in binary or BCD
format. The DM bit is set by the program to the appropriate format and can be read as required. This bit is
not modified by internal functions or

RESET

. A 1 in DM signifies binary data while a 0 in DM specifies

BCD data.

24/12 –

The 24/12 control bit establishes the format of the hours byte. A 1 indicates the 24-hour mode

and a 0 indicates the 12-hour mode. This bit is read/write and is not affected by internal functions of

RESET

DSE – The Daylight Savings Enable (DSE) bit is a read/write bit that enables two special updates when
DSE is set to 1. On the first Sunday in April, the time increments from 1:59:59 AM to 3:00:00 AM. On
the last Sunday in October when the time first reaches 1:59:59 AM, it changes to 1:00:00 AM. These
special updates do not occur when the DSE bit is a 0. This bit is not affected by internal functions
or

RESET
