ABSOLUTE MAXIMUM RATINGS*
Voltage Range on Any Pin Relative to Ground -0.3V to +7.0V
Operating Temperature Range 0 °C to +70°C
Storage Temperature Range -40 °C to +70°C
Soldering Temperature See IPC/JEDEC J-STD-020A (Note 7)
*This is a stress rating only and functional operation of the device at these or any other conditions beyond those indicated in the operation
sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods of time can affect reliability.
RECOMMENDED DC OPERATING CONDITIONS
(T
A
= 0
°
C to +70
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Power Supply Voltage V
CC
4.5 5.0 5.5 V 1
Input Logic 1 V
IH
2.2 V
CC
+ 0.3 V 1
Input Logic 0 V
IL
-0.3 0.8 V 1
DC ELECTRICAL CHARACTERISTICS (V
CC
= 4.5 to 5.5V, 0 °C to +70°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Power Supply Current I
CC1
7 15 mA 2
Input Leakage I
IL
-1.0 +1.0 mA 3
I/O Leakage I
LO
-1.0 +1.0 mA 4
Input Current I
MOT
-1.0 +500 mA 3
Output at 2.4V I
OH
-1.0 mA 1, 5
Output at 0.4V I
OL
4.0 mA 1
Write Protect Voltage V
TP
4.0 4.25 4.5 V
CAPACITANCE
(T
A
= +25
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 pF
Output Capacitance C
OUT
7 pF
