14
ATF1504AS(L)
0950N–PLD–07/02
Notes:
1. See ordering information for valid part numbers.
2. The t
RPA
parameter must be added to the t
LAD
, t
LAC
,t
TIC
, t
ACL
, and t
SEXP
parameters for macrocells running in the reduced-
power mode.
Input Test Waveforms and Measurement Levels
t
R
, t
F
= 1.5 ns typical
AC Characteristics (Continued)
Symbol
Parameter
-7
-10
-15
-20
-25
Units
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
t
ZX1
Output Buffer Enable Delay
(Slow slew rate = OFF;
V
CCIO
= 5.0V; C
L
= 35 pF)
4.0
5.0
7
9
10
ns
t
ZX2
Output Buffer Enable Delay
(Slow slew rate = OFF;
V
CCIO
= 3.3V; C
L
= 35 pF)
4.5
5.5
7
9
10
ns
t
ZX3
Output Buffer Enable Delay
(Slow slew rate = ON;
V
CCIO
= 5.0V/3.3V; C
L
= 35 pF)
9
9
10
11
12
ns
t
XZ
Output Buffer Disable Delay
(C
L
= 5 pF)
4
5
6
7
8
ns
t
SU
Register Setup Time
3
3
4
5
6
ns
t
H
Register Hold Time
2
3
4
5
6
ns
t
FSU
Register Setup Time of Fast Input
3
3
2
2
3
ns
t
FH
Register Hold Time of Fast Input
0.5
0.5
2
2
2.5
ns
t
RD
Register Delay
1
2
1
2
2
ns
t
COMB
Combinatorial Delay
1
2
1
2
2
ns
t
IC
Array Clock Delay
3
5
6
7
8
ns
t
EN
Register Enable Time
3
5
6
7
8
ns
t
GLOB
Global Control Delay
1
1
1
1
1
ns
t
PRE
Register Preset Time
2
3
4
5
6
ns
t
CLR
Register Clear Time
2
3
4
5
6
ns
t
UIM
Switch Matrix Delay
1
1
2
2
2
ns
t
RPA
Reduced-power Adder
(2)
10
11
13
14
15
ns
