11
ATF1504AS(L)
0950N–PLD–07/02
Notes: 1. Not more than one output at a time should be shorted. Duration of short circuit test should not exceed 30 sec.
2. When macrocell reduced-power feature is enabled.
Note: Typical values for nominal supply voltage. This parameter is only sampled and is not 100% tested.
The OGI pin (high-voltage pin during programming) has a maximum capacitance of 12 pF.
DC and AC Operating Conditions
Commercial Industrial
Operating Temperature (Ambient) 0
°C - 70°C
-40
°C - 85°C
V
CCINT
or V
CCIO
(5V) Power Supply 5V ± 5% 5V ± 10%
V
CCIO
(3.3V) Power Supply 3.0V - 3.6V 3.0V - 3.6V
DC Characteristics
Symbol Parameter Condition Min Typ Max Units
I
IL
Input or I/O Low
Leakage Current
V
IN
= V
CC
-2 -10 µA
I
IH
Input or I/O High
Leakage Current
2 10
I
OZ
Tri-state Output
Off-state Current
V
O
= V
CC
or GND -40 40 µA
I
CC1
Power Supply Current,
Standby V
CC
= Max
V
IN
= 0, V
CC
Std Mode
Com. 105 mA
Ind. 130 mA
“L” Mode
Com. 10 µA
Ind. 10 µA
I
CC2
Power Supply Current,
Power-down Mode V
CC
= Max
V
IN
= 0, V
CC
“PD” Mode 1 10 mA
I
CC3
(2)
Current in Reduced-power
Mode V
CC
= Max
V
IN
= 0, VCC
Std Power
Com 85 ma
Ind 105
V
CCIO
Supply Voltage 5.0V Device Output
Com. 4.75 5.25 V
Ind. 4.5 5.5 V
V
CCIO
Supply Voltage 3.3V Device Output 3.0 3.6 V
V
IL
Input Low Voltage -0.3 0.8 V
V
IH
Input High Voltage 2.0 V
CCIO
+ 0.3 V
V
OL
Output Low Voltage (TTL)
V
IN
= V
IH
or V
IL
V
CCIO
= MIN, I
OL
= 12 mA
Com. 0.45 V
Ind.
Output Low Voltage (CMOS)
V
IN
= V
IH
or V
IL
V
CC
= MIN, I
OL
= 0.1 mA
Com. .2 V
Ind. .2 V
V
OH
Output High Voltage (TTL)
V
IN
= V
IH
or V
IL
V
CCIO
= MIN, I
OH
= -4.0 mA
2.4 V
Pin Capacitance
Typ Max Units Conditions
C
IN
8 10 pF V
IN
= 0V; f = 1.0 MHz
C
I/O
8 10 pF V
OUT
= 0V; f = 1.0 MHz
