Page 30
30
9570H–AT42–02/10
AT42QT1110-MZ/AT42QT1110-AZ
REPEAT_TIME: selects the “repeat” time when “Timed” is selected as the trigger to start key
acquisition. The number entered is a multiple of 16 ms. If “0” is entered, the device will operate
in a continuous “free run” mode; that is, the QT1110 will not sleep after its cycle is completed but
will begin the next key acquisition cycle immediately.
Default KEY_AC value:
1 (timed)
Default MODE value:
0 (7-key mode)
Default SIGNAL value:
1 (parallel)
Default SYNC value:
1 (edge)
Default REPEAT_TIME value:
2 (32 ms cycle)
7.5
Address 1: Guard Key/Comms Options
GUARD_KEY: specifies the key (0 to 10) to be used as a guard channel (see
) .
GD_EN: enables the use of a guard key; 0 = disable, 1 = enable.
SPI_EN: enables the Quick SPI interface; 0 = disable, 1 = enable (see
See
for details of the Quick SPI Mode report.
To exit this mode (and clear the “SPI_EN” bit), the command “0x36” should be sent. To save the
settings to EEPROM and make Quick SPI mode active on startup, send the “Store to EEPROM”
command (0x0A). Any other data sent is ignored in Quick SPI mode.
CHG: the CHANGE pin mode (see
0 = “Data” mode. In this mode the “Change” pin is asserted to indicate unread data.
1 = “Touch” mode. In this mode the “Change” pin is asserted when a key is being touched
or is in detect.
CRC: enables or disables CRC; 0 = disable, 1 = enable. When this option is enabled, each data
exchange must have a CRC byte appended.
When report or setup data is being returned by the QT1110, a 1-byte checksum is returned. The
host should confirm that this checksum is correct and, if not, should request the report again.
Table 7-3.
Guard Key/Comms Options
Address
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1
GUARD_KEY
GD_EN
SPI_EN
CHG
CRC
Table 7-4.
Status Information Bytes
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Counter
1
Key 3 status
Key 2 status
Key 1 status
Key 0 status
2
Key 7 status
Key 6 status
Key 5 status
Key 4 status
3
Reserved
Key 10 status
Key 9 status
Key 8 status
4
Key 3 error
Key 2 error
Key 1 error
Key 0 error
5
Key 7 error
Key 6 error
Key 5 error
Key 4 error
6
Reserved
Key 10 error
Key 9 error
Key 8 error
