DS1685/DS1687

21 of 38

Up/Kickstart Timing Diagram” in the Electrical Specifications section of this data sheet. The timing
associated with these functions is divided into five intervals, labeled 1 to 5 on the diagram.

The occurrence of either a kickstart or wake-up condition causes the

PWR

pin to be driven low, as

described above. During Interval 1, if the supply voltage on the DS1685/DS1687 V

CC

pin rises above the

greater of V

BAT

or V

PF

before the power on timeout period (t

POTO

) expires, then PWR remains at the

active-low level. If V

CC

does not rise above the greater of V

BAT

or V

PF

in this time, then the

PWR

output

pin is turned off and returns to its high-impedance level. In this event, the

IRQ

pin also remains tri-stated.

The interrupt flag bit (either WF or KF) associated with the attempted power-on sequence remains set
until cleared by software during a subsequent system power-on.

If V

CC

is applied within the timeout period, then the system power-on sequence continues as shown in

Intervals 2 to 5 in the timing diagram. During Interval 2, PWR remains active and

IRQ

is driven to its

active-low level, indicating that either WF or KF was set in initiating the power-on. In the diagram,

KS

is

assumed to be pulled up to the V

BAUX

supply. Also at this time, the PAB bit is automatically cleared to 0

in response to a successful power-on. The

PWR

line remains active as long as the PAB remains cleared to

0.

At the beginning of Interval 3, the system processor has begun code execution and clears the interrupt
condition of WF and/or KF by writing 0’s to both of these control bits. As long as no other interrupt
within the DS1685/DS1687 is pending, the

IRQ

line is taken inactive once these bits are reset. Execution

of the application software can proceed. During this time, both the wake-up and kickstart functions can be
used to generate status and interrupts. WF is set in response to a date, hours, minutes, and seconds match
condition. KF is set in response to a low-going transition on KS. If the associated interrupt-enable bit is
set (WIE and/or KSE), then the

IRQ

line is driven active-low in response to enabled event. In addition,

the other possible interrupt sources within the DS1685/DS1687 can cause

IRQ

to be driven low. While

system power is applied, the on-chip logic always attempts to drive the

PWR

pin active in response to the

enabled kickstart or wake-up condition. This is true even if

PWR

was previously inactive as the result of

power being applied by some means other than wake-up or kickstart.

The system can be powered down under software control by setting the PAB bit to a logic 1. This causes
the open-drain

PWR

pin to be placed in a high-impedance state, as shown at the beginning of Interval 4 in

the timing diagram. As V

CC

voltage decays, the

IRQ

output pin is placed in a high-impedance state when

V

CC

goes below V

PF

. If the system is to be again powered on in response to a wake-up or kickstart, then

the both the WF and KF flags should be cleared and WIE and/or KSE should be enabled prior to setting
the PAB bit.

During Interval 5, the system is fully powered down. Battery backup of the clock calendar and NV RAM
is in effect and

IRQ

is tri-stated, and monitoring of wake-up and kickstart takes place. If PRS = 1,

PWR

stays active; otherwise, if PRS = 0,

PWR

is tri-stated.

RAM CLEAR

The DS1685/DS1687 provides a RAM clear function for the 242 bytes of user RAM. When enabled, this
function can be performed regardless of the condition of the V

CC

pin.
