DS1685/DS1687
15 of 38
NV RAM—RTC
The 242 general-purpose NV RAM bytes are not dedicated to any special function within the
DS1685/DS1687. They can be used by the application program as nonvolatile memory and are fully
available during the update cycle.
The user RAM is divided into two separate memory banks. When the bank 0 is selected, the 14 RTC
registers and 114 bytes of user RAM are accessible. When bank 1 is selected, an additional 128 bytes of
user RAM are accessible through the extended RAM address and data registers.
INTERRUPT CONTROL
The DS1685/DS1687 includes six separate, fully automatic sources of interrupt for a processor:
1) Alarm Interrupt
2) Periodic Interrupt
3) Update-Ended Interrupt
4) Wake-Up Interrupt
5) Kickstart Interrupt
6) RAM Clear Interrupt
The conditions that generate each of these independent interrupt conditions are described in greater detail
elsewhere in this data sheet. This section describes the overall control of the interrupts.
The application software can select which interrupts, if any, are to be used. There are a total of 6 bits,
including 3 bits in Register B and 3 bits in Extended Register B, that enable the interrupts. The extended
register locations are described later. Writing a logic 1 to an interrupt-enable bit permits that interrupt to
be initiated when the event occurs. A logic 0 in the interrupt enable bit prohibits the
IRQ pin from being
asserted from that interrupt condition. If an interrupt flag is already set when an interrupt is enabled, IRQ
is immediately set at an active level, even though the event initiating the interrupt condition might have
occurred much earlier. As a result, there are cases where the software should clear these earlier generated
interrupts before first enabling new interrupts
.
When an interrupt event occurs, the relating flag bit is set to a logic 1 in Register C or in Extended
Register A. These flag bits are set regardless of the setting of the corresponding enable bit located either
in Register B or in Extended Register B. The flag bits can be used in a polling mode without enabling the
corresponding enable bits.
However, care should be taken when using the flag bits of Register C as they are automatically cleared to
0 immediately after they are read. Double latching is implemented on these bits so that set bits remain
stable throughout the read cycle. All bits that were set are cleared when read and new interrupts that are
pending during the read cycle are held until after the cycle is completed. One, two, or three bits can be set
when reading Register C. Each used flag bit should be examined when read to ensure that no interrupts
are lost.
The flag bits in Extended Register A are not automatically cleared following a read. Instead, each flag bit
can be cleared to 0 only by writing 0 to that bit.
