ATA6827 [Preliminary]
7.
Noise and Surge Immunity
Parameters
Test Conditions
Value
Conducted interferences
ISO 7637-1
Level 4
(1)
Interference suppression
VDE 0879 Part 2
Level 5
ESD (Human Body Model)
ESD S 5.1
2 kV
CDM (Charged Device Model)
ESD STM 5.3.1-1999 all pins
500V
Note:
Test pulse 5: V
smax
= 40V
8.
Electrical Characteristics
7.5V < V
VS
< 40V; 4.75V < V
VCC
< 5.25 V; INH = High; –40°C
≤
T
j
≤
200
°
C; T
a
≤
150°C; unless otherwise specified, all values refer to
GND pins.
No.
Parameters
Test Conditions
Pin
Symbol
Min.
Typ.
Max.
Unit
Type*
1
Current Consumption
1.1
Quiescent current VS
V
VS
< 20V, INH = low
10, 11
I
VS
1
60
µA
A
1.2
Quiescent current VCC
4.75 V < V
VCC
< 5.25V,
INH = low
9
I
VCC
15
40
µA
A
1.3
Supply current VS
V
VS
< 20V normal
operating, all outputs off
10, 11
I
VS
4
6
mA
A
1.4
Supply current VCC
4.75V < V
VCC
< 5.25V,
normal operating
9
I
VCC
350
500
µA
A
1.5
Discharge current VS
V
VS
= 32.5V,
INH = low
10, 11
I
VS
0.5
5.5
mA
A
1.6
Discharge current VS
V
VS
= 40V,
INH = low
10, 11
I
VS
2.0
10
mA
A
2
Undervoltage Detection, Power-on Reset
2.1
Power-on reset
threshold
9
V
VCC
3.1
3.9
4.5
V
A
2.2
Power-on reset
delay time
After switching on V
CC
t
dPor
30
95
190
µs
A
2.3
Undervoltage-detection
threshold
V
CC
= 5V
10, 11
V
Uv
5.5
7.1
V
A
2.4
Undervoltage-detection
hysteresis
V
CC
= 5V
10, 11
∆
V
Uv
0.6
V
A
2.5
Undervoltage-detection
delay time
t
dUV
10
40
µs
A
3
Thermal Prewarning and Shutdown
3.1
Thermal prewarning set
T
jPW set
170
195
220
°C
B
3.2
Thermal prewarning
reset
T
jPW reset
155
180
205
°C
B
3.3
Thermal prewarning
hysteresis
∆
T
jPW
15
°C
B
3.4
Thermal shutdown off
T
j switch off
200
225
250
°C
B
3.5
Thermal shutdown on
T
j switch on
185
210
235
°C
B
*) Type means: A =100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter
Note:
1. Delay time between rising edge of the input signal at pin CS after data transmission and switch on output stages to 90% of
final level. Device not in standby for t > 1 ms
